Modern OSV / Seismic Support vessel Built 2009

From direct owner friends
Ref Offshore 1400-2009
Modern OSV / Seismic Support vessel
Built: 2009 at Fujian, China for present owner
Dwt: 1400 on 4,95 m draft
GT/NT: 1678 / 503
Flag: Marshall Islands
Class: BV I + HULL l + MACH, Tug; Supply Vessel-Unrestricted Navigation + AUT UMS- Fire
Fighting Vessel Class 1; Next SS 2019-01; Intermediate surveys overdue since 2017-04. Can be delivered these passed
Vessel laid up in Norway
Dimensions: Loa 59 Beam 15 Depth 6,1
Bollard Pull: 65 t
Deck: Area: 350 m2; Load: 500 ts; Strength 7,5 t/m2
Cabins: For total 42 persons incl. crew
Seismic Support Features:
-Davit for Crew Transfer Boat
-Towing Hook
-Reefer Containers
-Yokohama Fenders
Deck Machinery:
-Capstans 2 x 5 t
-Tugger Winch 2 x 10 t
-Deck crane telescopic 3t at 9m, 1,1 t at 19,5m max outreach
-FRC Davit Vestdavit PLR 7000
Anchor handling/towing Equipment
-Winch Mentrade with double drum; brake holding 200 t
-Line Pull 1st layer 150 t@ 6 m/min; 71 t @ 12 m/min; 50 t @18 m/min
-Drum Capacity 2 x 1000 m 56 mm wire
-Rope Reel 1 x 5 t (1000m 56 mm wire)
-Stern Roller SWL 180 t (4,5 x Ø1,6 m)
-Shark Jaws 1 x Karm SWL 300 t
-Towing Pins 2 x Karm with closed top
Main engine: 2 x Caterpillar 3516B; each 1920 kW / 5150 bhp at 1600 rpm; Total 3840 kW/ 10300 bhp
Auxiliaries: 3 x Volvo D16-340kW; Emergency Generator 1 x Volvo D5-62 kW
Bow thruster: 371 kW; CPP
Propellers: 2 x CPP in Kort Nozzles
Rudders 2 x High Lift
Speed and consumption: 13 / 16 ts; 10 / 6 ts
Consumption standby offshore: 3 t s
Tank capacities in cbm: FO 960 FW 370 Liquid mud 420 (currently dedicated as fuel tanks) Dry bulk 187
